Amplifier Module Specifications--

Rated Power (RMS@1%THD@230Vac)

: 500+100W@4ohm, THD 1%

Frequency Response: 20Hz-20KHz

Working Voltage: 85V-265Vac with PFC

Standby and Green Power: Yes (＜0.5W)

Signal-to-Noise Ratio: 80dB

Dampening Factor: ＞550 (8ohm load, 1KHz or less)

THD+N (typical): ＜0.1 (8ohm load 20Hz-20KHz)

Input Impedance: Balanced 20KΩ， Unbalanced 10KΩ

Input Connector: 1xXLR female, 1xXLR male

Gain: 26dB

Protection Circuit Protection: Short circuit protection, DC protection, under

voltage protection, temperature protection, overload protection.

Dante: selectable

DSP: 96KHz sample rate, fixed point DSP, Phase, All-in-the-past filter, 12

EQ, Crossover, Limiter, Driver free

800ms for each input and output Driver free.Manufacturer: BFF Audio
